Weighing Load Cell Sensor 10Kg for Electronic Kitchen Scale YZC-133 With Wires
Original price was: ₹390.00.₹244.92Current price is: ₹244.92. (Excl. 18% GST)
Price (Excl. GST): ₹244.92
Price (Incl. GST): ₹289.01
- Weighing Range: 0 ~ 10 kg.
- Rated Output: 1.0 ± 0.1mV / V.
- Non Linear Output: ± 0.03% F.S.
- Input Impedance: 1066 ± 10% Ω.
- Output Impedance: 1000 ± 10% Ω.
- Insulation Resistance: 2000 MΩ.
| Weight | 26 g |
|---|---|
| Dimensions | 120 × 50 × 40 mm |
22 in stock
64 in stock
Out of stock
8 in stock
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. Product Images are shown for illustrative purposes only and may differ from the actual product.
This is Weighing Load Cell Sensor 10Kg for Electronic Kitchen Scale YZC-133 With Wires.
This weighing Load Cell Sensor (sometimes called a strain gauge) can translate up to 10 kg of pressure (force) into an electrical signal. Each load cell is able to measure the electrical resistance that changes in response to, and proportional of, the strain (e.g. pressure or force) applied to the bar.
With this gauge, you will be able to tell just how heavy an object is, if an object’s weight changes over time, or if you simply need to sense the presence of an object by measuring strain or load applied to a surface. This straight bar load cell is made from an aluminum alloy and is capable of reading a capacity of 10KG of weight
It has Four lead wires which can be connected to HX711 A/D Pressure Sensor. It is easy to use with driving voltage 5-10V and produce the output voltage as per the force changes over it.
Installation of the Sensor is also the simple task, it needs to fix one end through the screw hole and the other end left floating state, according to the label indicates the direction of the gravitational force exerted particular attention must not directly push the white plastic cover part of the sensor in order to avoid damage.
Package Includes:
- 1 x Weighing Load Cell Sensor 10Kg for Electronic Scale
