SW1801P 4pin Normally open vibration sensor module
Original price was: ₹80.00.₹36.58Current price is: ₹36.58. (Excl. 18% GST)
Price (Excl. GST): ₹36.58
Price (Incl. GST): ₹43.16
- The working voltage of 3.3V-5V.
- Using the company’s high-sensitivity vibration switch, the default with SW-18015P vibration sensor.
- The comparator output, the signal clean, good waveform, driving ability, more than 15mA
- With a fixed bolt hole, easy to install.
- The use of wide voltage LM393 comparator.
12 in stock
28 in stock
23 in stock
Out of stock
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. Product Images are shown for illustrative purposes only and may differ from the actual product.
The SW1801P 4pin vibration sensor module for Arduino is equipped with all the essential components for easy operation. Simply supply power to the module, and it’s ready for use. By attaching it to an object, the module effectively detects whether the object is tilted, offering a straightforward digital output that indicates tilt status.
Utilizing the SW-460D or SW-520D tilt sensor, this module employs a ball rolling mechanism rather than a mercury-based design, making it safer and more reliable. It features an M3 mounting hole for easy installation on various surfaces. The onboard tilt switch is highly sensitive, making it commonly used for tilt detection in various applications. Visual indicators, including a power LED and a status LED, enhance usability by providing clear feedback on the module’s status.
When the object remains within a specified angle, the module outputs a logic LOW signal. However, when tilted beyond the threshold—typically ranging from 45 to 130 degrees—it switches to a logic HIGH signal. The sensor’s performance can vary with angular velocity, and it also serves as a vibration sensor, adding to its versatility. The module can easily interface with any microcontroller featuring a digital input, such as the 8051, PIC, SK40C, SK28A, and SKds40A, making it an excellent choice for various electronic projects.
Pin Connection:
-
VCC = 5V
-
GND = 0V.
-
DO = digital output from the module
Note: If the DO is not working, you might need to turn the on-board potentiometer to center.
SW1801P 4pin vibration sensor module Features:
- Multiple axes measurement
- High resolution and precision
- Easy to use and mount on any object.
- Low power consumption
- Cost-effective and compact size
- Digital output
Application:
- Tilt sensing for remote control devices.
- An automatic rotating display like in phone and tablet.
- Aircraft to indicate the position of aircraft with respect to the earth.
- Gaming devices
- Digital cameras and other consumer electronics
Package Includes:
- 1 x SW1801P 4pin Normally open vibration sensor module for Arduino
