3 Channel Path tracing Module
Original price was: ₹384.00.₹158.00Current price is: ₹158.00. (Excl. 18% GST)
Price (Excl. GST): ₹158.00
Price (Incl. GST): ₹186.44
- Working voltage: 5V
- Uses infrared light detection, anti-jamming capability, using CTRT5000 sensor, adjustable sensitivity, stable performance
- With lights, a fixed bolt hole for easy installation
5 in stock
6 in stock
8 in stock
192 in stock
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. Product Images are shown for illustrative purposes only and may differ from the actual product.
The 5V 3 Channel Path tracing Module is an essential component for robotics and automation projects, particularly for those using platforms like Arduino, AVR, ARM, or PIC microcontrollers. This module features three infrared sensors designed to detect the presence of a line or track on the ground, enabling robots to follow a designated path accurately.
Each sensor emits infrared light and measures the reflection from the surface beneath it. When the sensors detect a change in light intensity—typically when transitioning from a lighter surface to a darker line—they send signals to the microcontroller, allowing it to adjust the robot’s direction accordingly. This capability is crucial for applications such as automated vehicles, conveyor belts, and other robotic systems requiring precise navigation.
With a simple connection to a microcontroller, the module is easy to integrate into existing projects. Its reliable performance and straightforward design make it a popular choice among hobbyists and engineers looking to enhance their robotics applications.
Pin Definition:
- VCC Voltage Supply ( 5 V)
- GND Ground
- L Signal from L infrared sensor (high / low)
- C Signal from C infrared sensor (high / low)
- R Signal from R infrared sensor (high / low)
Features:
- 3 channel tracking sensors, must have in your Arduino DIY Robot Projects;
- Uses infrared light detection, anti-jamming capability, using CTRT5000 sensor, adjustable sensitivity, stable performance;
- Working voltage : 5V
- With lights, a fixed bolt hole for easy installation
Package Includes:
- 1 x 3 Channel Path tracing Module
