Official 7Semi 30V 10A Single Channel Motor Driver Vikram-3010
Original price was: ₹999.00.₹516.10Current price is: ₹516.10. (Excl. 18% GST)
Price (Excl. GST): ₹516.10
Price (Incl. GST): ₹609.00
-
6V–30V Wide Voltage Support
-
10A Continuous Current Capacity
-
Single-Channel Brushed DC Motor Driver
-
Bi-Directional Forward & Reverse Control
-
3.3V & 5V Logic Level Compatible
-
PWM & DIR Control Interface
-
Fully NMOS H-Bridge for High Efficiency
-
No External Heat Sink Required
-
Onboard Test Buttons for Quick Checking
-
Motor Output Status LEDs
-
Overcurrent & Over-Temperature Protection
-
Undervoltage Shutdown Safety
-
Logic Input Range: 1.8V–12V
-
Compatible with Arduino, Raspberry Pi & PLCs
3 in stock
10 in stock
62 in stock
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. Product Images are shown for illustrative purposes only and may differ from the actual product.
The 7Semi 30V 10A Vikram 3010 Single Channel Motor Driver is a high-performance and reliable solution designed to precisely control one brushed DC motor in a wide range of industrial, robotics, and automation applications. Operating across a broad input voltage range of 6V to 30V, this motor driver supports bi-directional motor control with an impressive continuous current rating of up to 10A, making it suitable for both light-duty and demanding motor control tasks.
One of the key strengths of the Vikram-3010 is its wide logic-level compatibility. It seamlessly accepts 3.3V and 5V control signals, allowing direct interfacing with popular microcontrollers and controllers such as Arduino, Raspberry Pi, ESP32, STM32, and PLC systems. Additionally, the driver supports PWM and DIR inputs with an extended logic voltage range from 1.8V to 12V, offering excellent flexibility across diverse control platforms.
Built using a fully NMOS-based H-Bridge architecture, the Vikram-3010 ensures high efficiency, low power loss, and stable motor operation without the need for an external heat sink under normal operating conditions. This efficient design enhances durability and simplifies system integration.
For quick validation and troubleshooting, the motor driver includes onboard test buttons that allow users to manually operate the motor without connecting a host controller. Integrated LED indicators provide real-time visual feedback of motor output status, making testing and diagnostics straightforward.
Safety and reliability are further reinforced through built-in protection mechanisms, including overcurrent protection, over-temperature shutdown, and undervoltage lockout. These features safeguard both the motor and the driver, ensuring long-term dependable performance.
Overall, the Vikram-3010 is a robust, user-friendly, and versatile DC motor driver ideal for robotics, conveyor systems, automation equipment, DIY electronics projects, and industrial motor control applications.
Features
- Bi-directional control for single channel brushed DC motor
- Operating voltage voltage range 6V to 30V
- continuous current 10A
- 3.3V and 5V logic level input.
- Buttons for quick testing.
- LEDs for motor output state.
- Overcurrent protection
- Over Temperature protection.
- Undervoltage shutdown.
- Fully NMOS H-Bridge for better efficiency and no heat sink is required
Package Includes
- 1x Official 7Semi 30V 10A Single Channel Motor Driver Vikram-3010
