KY-012 Active Buzzer Module
Original price was: ₹89.00.₹25.00Current price is: ₹25.00. (Excl. 18% GST)
Price (Excl. GST): ₹25.00
Price (Incl. GST): ₹29.50
- Operating Voltage– 3.5V – 5.5V
- Maximum Current– 30mA @ 5VDC
- Resonance Frequency– 2.5kHz ±300Hz
- Minimum Sound Output– 85Db @ 10cm
- Working Temperature– -20°C to 70°C
- Storage Temperature– -30°C to 105°C
- Dimensions– 18.5 x 15mm
23 in stock
24 in stock
Out of stock
9 in stock
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. Product Images are shown for illustrative purposes only and may differ from the actual product.
The KY-012 Active Buzzer Module is a simple 3-pin module that produces a clear, single-tone sound at 2.5 kHz. It operates without the need for pulse width modulation (PWM) or complex coding—just set the signal pin to HIGH to activate it.
Ideal for adding audio to electronics or Arduino projects, this module is easy to use and integrates seamlessly. It generates a continuous tone when the signal is high, making it perfect for applications requiring consistent sound, such as alarms, notifications, or detection systems. With its single-pin operation, it simplifies the process of incorporating sound into your projects, making it a practical choice for a variety of uses.
Features:
- Min/Max Operating Voltage +3.3V to +5V
- Maximum Current: 30mA
- Resonance Frequency: 2500Hz ± 300Hz continuous
- Minimum Sound Output 85Db @ 4in (10cm)
- Storage Temperature: -22°F to 221°F (-30°C to 105°C)
- Operating Temperature: -4°F to 158°F (-20°C to 70°C)
- Dimensions: 0.73in X 0.59in (18.5mm X 15mm)
Package Includes:
- 1x KY-012 Active Buzzer Module
