MSP-EXP430FR2433 – LaunchPad Development Kit (with Sensing MCU, LaunchPad, BoosterPack Connector)
Original price was: ₹3,999.00.₹1,249.00Current price is: ₹1,249.00. (Excl. 18% GST)
Price (Excl. GST): ₹1,249.00
Price (Incl. GST): ₹1,473.82
- ULP FRAM technology based MSP430FR2433 16-bit MCU
- EnergyTrace Technology available for ultra-low-power debugging
- 20-pin LaunchPad kit standard leveraging the BoosterPack ecosystem
- On-board eZ-FET debug probe
- 2 buttons and 2 LEDs for user interaction
3 in stock
3 in stock
23 in stock
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. Product Images are shown for illustrative purposes only and may differ from the actual product.
The MSP-EXP430FR2433 LaunchPad™ Development Kit is a compact, cost-effective evaluation platform designed for engineers and developers working with MSP430FR2433 Value Line Sensing microcontrollers. Ideal for both beginners and experienced embedded developers, this LaunchPad offers a seamless way to get started with ultra-low-power embedded applications.
Powered by the MSP430FR2433 MCU, this board is based on Ferroelectric RAM (FRAM) technology, delivering fast write speeds, high endurance, and low power consumption—perfect for battery-powered and energy-harvesting applications. The integrated onboard eZ-FET debug probe enables easy programming, real-time debugging, and energy consumption measurement without requiring additional tools.
With two programmable buttons and two user LEDs, the MSP-EXP430FR2433 board allows quick prototyping and custom user interfaces. Additionally, it includes headers for BoosterPack™ plug-in modules, extending the board’s functionality for wireless communication, sensors, and display add-ons.
One of the most notable features is support for supercapacitor backup power, offering an alternative to traditional batteries. This feature allows developers to build stand-alone, rechargeable systems for smart sensing and industrial monitoring applications.
Whether you’re working on IoT edge nodes, portable medical devices, smart meters, or wearable electronics, this board is an excellent entry point into low-power microcontroller design.
For Datasheet click Here.
Features
- 1.8-V to 3.6-V operation
- 16-bit RISC architecture up to 16-MHz system clock and 8-MHz FRAM access
- 15KB of program FRAM, 512B of information FRAM, and 4KB of RAM
- 8-channel 10-bit ADC
- Four 16-Bit timers
- Two timers with three capture/compare registers each (Timer_A3)
- Two timers with two capture/compare registers each (Timer_A2)
- 32-bit hardware multiplier (MPY)
- 19 GPIOs
- Two enhanced universal serial communication interfaces (eUSCI_A) support UART, IrDA, and SPI
Resources
Package Incldues
- 1x MSP-EXP430FR2433 LaunchPad Development Kit
- 1x Micro USB Cable
