Official LAUNCHXL-TMS57004 Hercules TMS570LS04x/03x LaunchPad Development Kit

The Hercules TMS570LS04 LaunchPad Development Kit is an inexpensive evaluation platform designed to help users evaluate and get started on development with Hercules microcontroller platform. The LaunchPad Development Kit is based on the IEC 61508 SIL 3 and ISO 26262 ASIL D certified TMS570LS0432, which is a dual core lock-step ARM Cortex-R4 based MCU with features like 12-bit ADC, N2HET with programmable timer pins, eQEP, MibSPI and serial communication interfaces. Hercules TMS570 MCUs can help reduce the development effort of IEC 61508 and ISO 26262 functional safety applications.

The LaunchPad comes pre-programmed with Hercules Safety MCU Demo enabling users to easily learn about the key safety, data acquisition and control features of the Hercules MCU platform.

The LaunchPad features on-board emulation for programming and debugging, on-board buttons, LEDs and ambient light sensor & the standard 40 pin BoosterPack-compatible expansion header to support a wide range of plug-in modules for added functionality such as displays & more.

Features:

• USB powered
• On board USB XDS100v2 JTAG debug
• On board SCI to PC serial communication
• Two LEDs
• Reset switches
• Ambient light sensor
• 40 pin BoosterPack XL Header
• Footprint for an expansion header (not populated) to bring out all MCU Pins
• External high-speed emulation via 14-pin TI-JTAG header (not populated)

Documents:

• Design files:
  • TMS570LS0432x LaunchPad Schematic
  • TMS570LS0432x LaunchPad BOM
  • TMS570LS0432x LaunchPad Gerber Files
  • TMS570LS0432x LaunchPad PCB Layout
• User Guide:
  • TMS570LS0x32 16- and 32-Bit RISC Flash Microcontroller datasheet
  • TMS570LS04x/03x 16/32-Bit RISC Flash Microcontroller Technical Reference Manual
  • Hercules TMS570LS0432 / RM42L432 LaunchPad User’s Guide

Package Includes:

• 1 x TMS570LS0432 LaunchPad Evaluation board
• 1 x USB micro cable
• 1 x Quick Start Guide
