INA240 Current Detection Amplifier Current Voltage Monitoring Bidirectional Module
Original price was: ₹499.00.₹312.71Current price is: ₹312.71. (Excl. 18% GST)
Price (Excl. GST): ₹312.71
Price (Incl. GST): ₹369.00
- Wide -4V to 80V common-mode range
- Enhanced PWM suppression
- 200V/V fixed gain
- Analog voltage output
- Ideal for motor & solenoid control
3 in stock
Out of stock
Out of stock
30 in stock
Please note that the product information provided on our website may not be entirely accurate as it is collected from various sources on the web. While we strive to provide the most up-to-date information possible, we cannot guarantee its accuracy. We recommend that you always read the product labels, warnings, and directions before using any product. Product Images are shown for illustrative purposes only and may differ from the actual product.
The INA240 current detection module is a precision current-sensing amplifier, ideal for high-side or low-side current measurement in motor drives, power management systems, and solenoid control. With a wide common-mode voltage range from -4V to 80V, it enables accurate differential sensing across shunt resistors even in complex environments. The enhanced PWM rejection technology ensures minimal output ripple and high measurement integrity in fast-switching systems. Operating at 3V to 5V, with a fixed gain of 200V/V, this module offers a compact and reliable solution for embedded applications where stability, speed, and efficiency matter.
Features
- Wide -4V to 80V common-mode input voltage range
- Enhanced PWM suppression for accurate current sensing
- High CMRR: 132dB DC / 93dB AC at 50kHz
- Works with 3.0V–5.0V supply voltage
- Fixed gain: 200V/V (INA240A4 variant)
- Suitable for both high-side and low-side sensing
Package Includes
- 1 x INA240 current detection module proxy
- 1 x Header Pin
